Generating an ultra-tight 4° beam from each of the 18 pixels, they combine to produce a bright, defined “sheet” of light, desired by Lighting Designers. Seamless curtains of light can be constructed using several fixtures as the detailed design allows any combination of TETRA1™ and TETRA2™ to be placed end to end on stage or truss, whilst maintaining equal spacing between pixels. With the addition of two exclusive Robe patented MCFE™ – Multi-Coloured Flower Effects, the pixel-driven Tetra1 sets itself apart from others by projecting charismatic in- air animations.

The homogenised beams, together with the smooth 11:1 zoom, provide; a wash out to 45°, a footlight, a wall graze or dynamic in-air effects with fast paced sweeping movements. Utilizing our latest L3™ (Low Light Linearity) dimming system for an imperceptible fade to black, the 18-bit control provides ultra-smooth colour mixing across the full colour spectrum. An embedded Ethernet switch and wide range of protocols (sACN, Art-Net or Kling-Net) allow a quick network installation and ease of control from media servers, DMX or the internal effects engine.

Light source

18x 40 W RGBW LED multichips

Light output

10.500 lm

Zoom range

4° - 45°

Effects

2x MCFE™ - Multi-Coloured Flower Effects – creating spectacular multicolour beam effects in the air rotating in both directions at variable speed (patented), pixel control, virtual colour wheel, tungsten lamp effect

Innovations

DataSwatch™ - inbuilt virtual colour library

The DataSwatch™ inbuilt virtual colour library for Robe LED fixtures consists of up to 237 pre-programmed and calibrated colours and tones, allowing for rapid and accurate programming.

MCFE™ - Multi Coloured Flower Effect

The Robe patented MCFE™ – Multi-Coloured Flower Effect – creates sharp, multi-coloured spikes of light, that are fully rotatable in both directions, at variable speeds.

L3™ - Low Light Linearity System

The L3™ Low Light Linearity System produces imperceptible, ultra-smooth fades to black.

REAP™ - Robe Ethernet Access Portal

The Robe Ethernet Access Portal allows to access internal data from a networked fixture, viewed as a web page, addressable via the fixtures network IP.

RLCT™ - Robe lens coating technology

Just like with spectacles, our lens coating technology protects soft plastic lenses against surface scratches, that can even occur during cleaning when scrubbed repeatedly. Anti-static properties prevent dust build-up on the lenses, thus extending the period between maintenance cleaning.

GDTF – General Device Type Format

The General Device Type Format creates a unified definition for exchange of data for the operation of intelligent luminaries, such as moving lights. The file format is human readable and developed using open source formats.

Tungsten Emulation

When selected, the luminaire will mimic the colour temperature of a tungsten lamp as you lower the output to produce that classic warm glow.

QVGA Robe Touch Screen Display System

The QVGA Robe touch screen display gives full access to all fixture setup and diagnostic functions and is very intuitive to navigate.

Product Video

Accessories

Technical Specification

Expand AllDownload PDFCollapse All

Source

Light source type: 18x 40W RGBW LED multichips

LED life expectancy: min. 50.000 hours

Typical lumen maintenance: L70/B50 @ 50.000 hours

Optical system

Dynamic Effects and Features

Colour mixing mode RGBW or CMY

Individual control of each RGBW pixel

Variable CCT: 2.700K - 8.000K

Tungsten lamp effect: 750W, 1.000W, 1.200W, 2.000W, 2.500W lamp emulation for whites from 2.700K to 4.200K (red shift and thermal delay)

DataSwatch™ filters: pre-programmed 237 colours and tones including most used whites 2.700K, 3.200K, 4.200K, 5.600K and 8.000K

Pre-programmed pixel effects with colour, dimming and strobe chases, waves and pulses at variable speed and direction

2x MCFE™ - Multi-Coloured Flower Effects – creating spectacular multicolour beam effects in the air rotating in both directions at variable speed (patented)

Motorized zoom

2 independent zoom zones

Pre-programmed random strobe & pulse effects

Electronic strobe effect with variable speed up to 20 Hz

High resolution electronic dimming: 0 - 100%

L3™ - (Low Light Linearity) Imperceptible 18 bit dimming for ultra smooth fade to black

Control and programming

Setting & Addressing: QVGA Robe touch screen with battery backup, gravitation sensor for auto screen positioning, operation memory service log with RTC, stand-alone operation with 3 editable programs (each up to 88 steps), built-in analyser for easy fault finding

Protocols: USITT DMX-512, RDM, Art-Net, MA Net, MA Net2, sACN, Kling-Net

REAP™ - Robe Ethernet Access Portal

Wireless CRMX™ technology from Lumen Radio - on request

DMX Protocol modes: 6

Control channels: 34, 56, 97, 115, 110, 128

RGBW / CMY: 8 or 16 bit

Zoom: 8 or 16 bit

Dimmer: 8 or 16 bit (internal 18 bit)

Movement

Thermal specification

Electrical specification and connections

Mechanical specification

Rigging

Included items

Optional accessories
